Affine vs perspective bilinear transformation

[toowren]

Let's say there is an arbitrary composite (wall.png) shape in PixiJS.



I need to project a texture onto it by some kind of a grid warp in a way, so the result would be similar to output.png.



I have tried to do it via PIXI.SimplePlane and it seems that default projection algorithm at this framework is affine transformation. And the result have to be based on quad bi-linear projection.






const app = new PIXI.Application({ width: 512, height: 324, antialias: true });
document.body.appendChild(app.view);

app.loader.add('pattern', pattern64).load(inits);

function inits() {

    const graphics = new PIXI.Graphics();

    let path = [34, 100, 176, 100, 176, 224, 34, 224];

    graphics.lineStyle(0);
    graphics.beginFill(0xBCBCBC, 1);
    graphics.drawPolygon(path);
    graphics.endFill();

    path = [176, 100, 258, 60, 258, 264, 176, 224];

    graphics.lineStyle(0);
    graphics.beginFill(0xCDCDCD, 1);
    graphics.drawPolygon(path);
    graphics.endFill();

    path = [258, 60, 422, 104, 422, 220, 256, 264];

    graphics.lineStyle(0);
    graphics.beginFill(0x606060, 1);
    graphics.drawPolygon(path);
    graphics.endFill();

    path = [422, 104, 478, 104, 478, 220, 422, 220];

    graphics.lineStyle(0);
    graphics.beginFill(0x909090, 1);
    graphics.drawPolygon(path);
    graphics.endFill();

    app.stage.addChild(graphics);

    const texture = app.loader.resources.pattern.texture;

    const plane = new PIXI.SimplePlane(texture, 5, 3);
    app.stage.addChild(plane);

    let buffer = plane.geometry.getBuffer('aVertexPosition');

    // graphics.beginFill(0xFF0000);
    // graphics.drawRect(buffer.data[20], buffer.data[21], 8, 8);
    // graphics.endFill();

    //manually set just for this demo
    buffer.data[0] = 34;
    buffer.data[1] = 100;
    buffer.data[2] = 176;
    buffer.data[3] = 100;
    buffer.data[4] = 258;
    buffer.data[5] = 60;
    buffer.data[6] = 422;
    buffer.data[7] = 104;
    buffer.data[8] = 478;
    buffer.data[9] = 104;

    buffer.data[10] = 34;
    buffer.data[11] = 162;
    buffer.data[12] = 176;
    buffer.data[13] = 162;
    buffer.data[14] = 258;
    buffer.data[15] = 162;
    buffer.data[16] = 422;
    buffer.data[17] = 162;
    buffer.data[18] = 478;
    buffer.data[19] = 162;

    buffer.data[20] = 34;
    buffer.data[21] = 224;
    buffer.data[22] = 176;
    buffer.data[23] = 224;
    buffer.data[24] = 258;
    buffer.data[25] = 264;
    buffer.data[26] = 422;
    buffer.data[27] = 220;
    buffer.data[28] = 478;
    buffer.data[29] = 220;

    buffer.update();

}



The code returns output2.png



Yes, PixiJS has additional projections plugin (https://pixijs.io/examples/#/plugin-projection/quad-homo.js), but it seems that output could be controlled just by four corner points. In my case, I need more. At least 10 or even 15.



If I couldn't use projection plugin, maybe there is a way to implement a custom shader for aVertexPositions and UVs?!







[ivan.popelyshev]

> but it seems that output could be controlled just by four corner points. In my case, I need more. At least 10 or even 15.

You are , honestly, first or second user who needs bilinear. I made that demo as a way to show "we can do it". I couldnt do the whole way with mesh because of time. I had to stop somewhere: I didnt know whether there are ppl who need it, and there were so many other features in other plugins that were needed.

How to proceed? There are several ways, I suppose:

1. you do it yourself, using my bilinear shader. Yes, shader needs adjustments - need to move all those bilinear things into arguments instead of uniforms, either re-set uniforms and call shader for each quad separately.

2. post a discussion with a bounty on it in https://github.com/pixijs/pixijs/discussions , and i'll take it
3. try to persuade someone in pixijs discord to do it.

Edited October 8, 2022 by ivan.popelyshev
