Skymaterial from material library is broken for me

[KevinBLT]

Hello everyone,



I hope you had great holidays!



I am back at work now and found these new materials very interesting.

While implementing the new "sky material", I encountered the following error:



File: /dist/babylon.skyMaterial.js

        this._effect = scene.getEngine().createEffect(shaderName, attribs, ["world", "viewProjection",                    "vFogInfos", "vFogColor", "pointSize", "vClipPlane",                    "luminance", "turbidity", "rayleigh", "mieCoefficient", "mieDirectionalG", "sunPosition"                ], [], join, fallbacks, this.onCompiled, this.onError);            }            if (!this._effect.isReady()) { // <=== this._effect is null, therefore error "isReady of null"                return false;            }            this._renderId = scene.getRenderId();            this._wasPreviouslyReady = true;

this._effect.isReady() throws an error because this._effect is null.



What's the problem here?



Thanks



Kevin

[GameMonetize]

@Luuacro will soon be able to answer your question

[julien-moreau]

Hey Kevin,

I reproduced the bug and fixed it (the pull request was done).

For instance, you can replace the line 113 in the TS by

...
Line 113 : "if (!this._defines.isEqual(this._cachedDefines) || !this._effect) {"
...



[RaananW]

it is now merged :-)

[KevinBLT]

I thank you guys a lot! It's working now and looks really nice.

I have some problems with the usability:

Is there really no way to set the "sun's" position? Even rotating the box doesn't work, so I am not able to match the sun on the texture with the real directional light I am already using in this project. What could I do? There is an internal "_sunPosition" in the skymaterial, but it's not changeable from the outside.

[julien-moreau]

I see what you mean, I'll add a function that returns the potential position of the sun according to a given position (BABYLON.Vector3)

The material doesn't work on the nodes transformations, but only on pixels visible, you'll not be able to animate the sky by moving or rotating the box. For instance, just use the .inclination and .azimuth properties. I come back sure when I have implemented the function

[julien-moreau]

You can still play with the Sky material here : http://babylonjs-extras.azurewebsites.net/materialsLibrary/test/

Or the playground example here : http://www.babylonjs-playground.com/#E6OZX#6

[KevinBLT]

Thanks. I was able to set it to the right values with this.

But now the sun is in the west for me. I really need it in the south. I cannot rotate everything else - would be a lot more work (scene is real time constructed out of parameters).

Is it impossible to attach it to the box rotation anyhow?

[KevinBLT]

Quote

But now the sun is in the west for me. I really need it in the south. I cannot rotate everything else - would be a lot more work (scene is real time constructed out of parameters).

Is it impossible to attach it to the box rotation anyhow

Nothing possible with this?

[julien-moreau]

Oh, just looking for your post (thanks Deltakosh)

You should modify the .azimuth property of the material to set the orientation of the sun. Looks like you already modified to inclination

Getting the good result by giving the position of the sun is still in my roadmap

[KevinBLT]

Ah yes.

I played and had inclination set to 0 before. Then  azimuth only changed the "height".

I've played again and it's perfect now.

I thank you a lot! It's better than every skytexture I could imagine.

Do you think there will come something like a "cloud generator" also?
