Undefined object error coming for basic tiled implementation

rishavs · February 9, 2016

<!DOCTYPE HTML>
<html>
    <head>
        <title>Phaser Tiled Test</title>
    </head>
    <body>
        <div id="renderer_container">
            <!-- /renderer_container -->
        </div>

        <script src="phaser.min.js"></script>
        <script src="main.js"></script>
    </body>
</html>

var map;
var layer;
var keyArrow;

var game = new Phaser.Game(800, 600, Phaser.AUTO, 'renderer_container', {
		preload : preload,
		create : create,
		update : update,
		render : render
	});

function preload() {

	game.load.tilemap('map', 'testMap.json', null, Phaser.Tilemap.TILED_JSON);
	game.load.image('tiles', 'map.png');

}

function create() {

	map = game.add.tilemap('map');

	//  Now add in the tileset
	map.addTilesetImage('tiles');

	//  Create our layer
	layer = map.createLayer(0);

	//  Resize the world
	layer.resizeWorld();

	//  Allow keyArrow to scroll around the map
	keyArrow = game.input.keyboard.createCursorKeys();

	var help = game.add.text(16, 16, 'Arrows to scroll', {
			font : '14px Arial',
			fill : '#ffffff'
		});

	help.fixedToCamera = true;
}

function update() {
	if (keyArrow.left.isDown) {
		game.camera.x -= 4;
	} else if (keyArrow.right.isDown) {
		game.camera.x += 4;
	}

	if (keyArrow.up.isDown) {
		game.camera.y -= 4;
	} else if (keyArrow.down.isDown) {
		game.camera.y += 4;
	}

}

function render() {}

Hi

Just learning phaser. I am trying to load a simple tiled map.

But i am getting an undefined exception for the "map" object.

fillmoreb · February 9, 2016

I've copied your code locally, changing it only to use an image and tilemap json I had on hand, and it runs fine. Post a copy of your image and your json, and I'll see if I get the same error as you when I use those.

rishavs · February 22, 2016

Hi

Sorry, I was on vacation for a while.

Attaching the map that I used. Hopefully you can tell me what am i doing wrong.

Thanks.

testMap.json

rishavs · March 11, 2016

Sorry for thread necromancy. But can anyone help?

drhayes · March 11, 2016

Turn off compression in Tiled when you save your map. Everything else looks okay.

rishavs · March 15, 2016

I am now getting

Quote

Uncaught TypeError: map.addTilesetImage is not a function

from main.js:34

P4nch0 · March 15, 2016

Try to add the name of tile set what you give in tiled editor, like this example:

// The first parameter is the tileset name, as specified in the Tiled map editor (and in the tilemap json file)
// The second parameter maps this name to the Phaser.Cache key 'tiles'

map.addTilesetImage('SuperMarioBros-World1-1', 'tiles');

http://phaser.io/examples/v2/loader/load-tilemap-json

rishavs · March 15, 2016

didnt help.

I am thinking the problem is in the

map = game.add.tilemap('mapJSON');

line. If it had worked properly, i should have that method in my map object.

P4nch0 · March 15, 2016

When i try Your code i will be know more, but now i am in work.

Maybe try that:

this.map.addTilesetImage('tiles');

rishavs · March 15, 2016

just did. Didnt work.

Thanks for trying.I'll wait till you have run the code.

P4nch0 · March 15, 2016

Hi Man,

Sory but i cant run your project, i dont know how it work because i dont create it ..

I am not sure, but when i try to run isometric map in phaser i cant to do it because that map was unavailable, but maybe someone who knows more can tell You something.

Try this course, i was started using phaser with it:

https://gamedevacademy.org/html5-phaser-tutorial-top-down-games-with-tiled/

AzraelTycka · March 15, 2016

Hello,

I only copied your code and used your files externally and got some errors in console.

phaser.min.js:11   Phaser v2.4.6 | Pixi.js v2.2.9 | WebGL | WebAudio     http://phaser.io ♥♥♥
phaser.min.js:25 TilemapParser.parseTiledJSON - Only orthogonal map types are supported in this version of Phaser
phaser.min.js:20 TypeError: Cannot read property 'length' of undefined(…)f.onload @ phaser.min.js:20
main.js:44 Uncaught TypeError: Cannot read property 'left' of undefined

Well unless I missed something from your posts I can even replicate the same error you get.

rishavs · March 16, 2016

I updated my version of Phaser and I am getting the same error as your are.

I am beginning to think this is the culprit - "TilemapParser.parseTiledJSON - Only orthogonal map types are supported in this version of Phaser"

My map is staggered isometric.

P4nch0 · March 16, 2016

Yeah, this is the same error what i had when i tried to load isometric map. Try normal map, when you have nice tile set, the map can look great too
