JCPalmer Posted April 5, 2016 Share Posted April 5, 2016 I think I found a way (actually 2)s to reduce a Blender export file. I noticed normals, UV's, shape keys are always values > -1 and < 1. Even many positions could be in this range. I popped this little piece of code, which if it error-ed would cause my scene to not display: var zeroless = new Float32Array([-.3333,.3709]); Scene did not fail. I will soon be updating the in-line code generator to see it works like: this.setVerticesData(BABYLON.VertexBuffer.PositionKind, new Float32Array([-.3333,.3709 ... My question is: are there any platforms, or JSON, where this cannot occur? Blender is shipping up to 4 decimals (stripping trailing), so normals & UV's this a 1/8 reduction for negative numbers with no trailing 0's, and 1/7 for positive. Shapekeys should probably be always 0 to .9999, so 1/7 for them. Speaking of 4 decimals, the second reduction I want to try is changing the test for equality of vertices / normals / UV's. Right now they use ==, but I have made a function for shape key analysis to only test equality to the number of decimals output. I have been slowing adding it in more and more places. def same_vertex(vertA, vertB): if vertA is None or vertB is None: return False return (round(vertA.x, MAX_FLOAT_PRECISION_INT) == round(vertB.x, MAX_FLOAT_PRECISION_INT) and round(vertA.y, MAX_FLOAT_PRECISION_INT) == round(vertB.y, MAX_FLOAT_PRECISION_INT) and round(vertA.z, MAX_FLOAT_PRECISION_INT) == round(vertB.z, MAX_FLOAT_PRECISION_INT)) This has had more effect so far than you might think. Blender is quad based, so when the exporter makes a temp version as triangles one point might be 16.3456789 and another might be 16.2356794. The point here is not really about space, but smoothness. The stuff being exported just does not look as good as it does in Blender in crease areas. I am thinking it might be some sort of flat-shading effect due to extra verts. Might even add a superSmooth arg on tester, where the test is using 3 decimals, just to see what happens: def same_vertex(vertA, vertB, superSmooth = False): precision = MAX_FLOAT_PRECISION_INT - (1 if superSmooth else 0) if vertA is None or vertB is None: return False return (round(vertA.x, precision) == round(vertB.x, precision) and round(vertA.y, precision) == round(vertB.y, precision) and round(vertA.z, precision) == round(vertB.z, precision)) Quote Link to comment Share on other sites More sharing options...
JCPalmer Posted April 5, 2016 Author Share Posted April 5, 2016 Well, I have thought of one instance where the 0 IS NOT optional, when the value is 0.0000 . The formatter code already drops the '.' too in that case. Other than that, the question still stands? Quote Link to comment Share on other sites More sharing options...
Pryme8 Posted April 5, 2016 Share Posted April 5, 2016 not sure, id do a test of performance of with a leading 0 and without. Im not super versed in this topic, but I would assume that if you leave out a leading 0 at some point javascript would have to add one back in? I mean maybe not but how else could it do calculations without having a fully constructed number? So this is where I would be interested. Ill dig through the number and math class some and try to figure that out, but I would assume the drop in the export would not be that substantial? I mean whats a 0, one bit? How many times and how large would your file need to be for that to take an effect? now, as far as which would be faster still begs to differ? for all I know leaving the 0 out will increase calculation speed by skipping over a functional step, or perhaps its the opposite. If you find out more about this please let me know, I would like to tailor my habits to match the most effective standard. Quote Link to comment Share on other sites More sharing options...
JCPalmer Posted April 5, 2016 Author Share Posted April 5, 2016 Each character in an ascii file is 8bits. The removal on an output with 2 meshes (body wt 12 shape keys & hair) reduced the file size by 11.5%. It worked. The export, whether .babylon or in-line JS is about 96% numbers, so 1/8 (12.5%) would be approachable if indexes were not integers instead of floats. In Javascript, once read each value is going to be a float 64. BJS converts that to a float 32. The difference in parsing time is probably not significant. The extra code to produce the data only increased from 8.0305 sec to 8.1185 sec. Hard to pin that amount of time on this. It varies some without any changes. I did not code this to be efficient. Here is the process in python. Perhaps, someone could write an equivalent in JS for the serializer. def format_f(num): s = MAX_FLOAT_PRECISION % num # rounds to N decimal places while changing to string s = s.rstrip('0') # strip trailing zeroes s = s.rstrip('.') # strip trailing . s = '0' if s == '-0' else s # nuke -0 asNum = float(s) if asNum != 0 and asNum > -1 and asNum < 1: if asNum < 0: s = '-' + s[2:] else: s = s[1:] return s The interesting part of the log file, basically 17k verts processing begun of mesh: Body processing begun of Standard material: Body:Young_asian_female Diffuse texture found "young_lightskinned_female_diffuse3" Image texture found, type: diffuseTexture, mapped using: "UVMap" WARNING: Opacity non-std way to indicate opacity, use material alpha to also use Opacity texture processing begun of Standard material: Tongue01:Tongue01material Diffuse texture found "tongue01_diffuse" Image texture found, type: diffuseTexture, mapped using: "UVMap" WARNING: Opacity non-std way to indicate opacity, use material alpha to also use Opacity texture processing begun of Standard material: Teeth_base:Teethmaterial Diffuse texture found "teeth" Image texture found, type: diffuseTexture, mapped using: "UVMap" WARNING: Opacity non-std way to indicate opacity, use material alpha to also use Opacity texture processing begun of Standard material: Eyelashes02:Bodymaterial Diffuse texture found "eyelashes02" Image texture found, type: diffuseTexture, mapped using: "UVMap" WARNING: Opacity non-std way to indicate opacity, use material alpha to also use Opacity texture processing begun of Standard material: Eyebrow001:Eyebrow001 Diffuse texture found "eyebrow001" Image texture found, type: diffuseTexture, mapped using: "UVMap" WARNING: Opacity non-std way to indicate opacity, use material alpha to also use Opacity texture processing begun of Standard material: High-poly:Eye_deepblue Diffuse texture found "deepblue_eye" Image texture found, type: diffuseTexture, mapped using: "UVMap" WARNING: Opacity non-std way to indicate opacity, use material alpha to also use Opacity texture processing begun of multimaterial: voice_sync_female.Multimaterial#0 num positions : 12674 num normals : 12674 num uvs : 25348 num uvs2 : 0 num colors : 0 num indices : 58812 Shape Keys: MakeHuman shape key consolidation performed shape key "FACE-MOUTH_OPEN": n verts different from basis: 4116 shape key "FACE-LIPS_LOWER_IN": n verts different from basis: 420 shape key "FACE-LIPS_PART": n verts different from basis: 429 shape key "FACE-MOUTH_WIDE": n verts different from basis: 603 shape key "FACE-MOUTH_UP": n verts different from basis: 717 shape key "FACE-LIPS_MID_UPPER_UP": n verts different from basis: 284 shape key "FACE-LIPS_MID_LOWER_DOWN": n verts different from basis: 160 shape key "FACE-TONGUE": n verts different from basis: 284 shape key "FACE-HAPPY": n verts different from basis: 3286 shape key "FACE-SAD": n verts different from basis: 5460 shape key "FACE-ANGRY": n verts different from basis: 3160 shape key "FACE-SCARED": n verts different from basis: 5974 shape key "FACE-LAUGHING": n verts different from basis: 6722 shape key "FACE-CRYING": n verts different from basis: 4005 shape key "FACE-DETERMINED": n verts different from basis: 2975 shape key "FACE-STRUGGLING": n verts different from basis: 4466 shape key "FACE-DISGUSTED": n verts different from basis: 3902 shape key "FACE-SKEPTICAL": n verts different from basis: 1081 shape key "FACE-CUSTOM1": n verts different from basis: 1794 shape key "FACE-CUSTOM2": n verts different from basis: 6119 Shape-key group, FACE, # of affected vertices: 8100, out of 12674 processing begun of mesh: Long01 processing begun of Standard material: Long01:Long01 Diffuse texture found "long01_diffuse" Image texture found, type: diffuseTexture, mapped using: "UVMap" WARNING: Opacity non-std way to indicate opacity, use material alpha to also use Opacity texture num positions : 3415 num normals : 3415 num uvs : 6830 num uvs2 : 0 num colors : 0 num indices : 12324 ========= Writing of files started ========= ========= Writing of files completed ========= ========= end of processing ========= elapsed time: 0 min, 8.1066 secs Pryme8 1 Quote Link to comment Share on other sites More sharing options...
fenomas Posted April 6, 2016 Share Posted April 6, 2016 Javascript definitely doesn't require a zero before the decimal point, per the spec. Linters may complain but it should be completely safe! GameMonetize and JCPalmer 2 Quote Link to comment Share on other sites More sharing options...
GameMonetize Posted April 6, 2016 Share Posted April 6, 2016 Agree with fenomas. This SHOULD (!!) not be a problem and it deserves a try Quote Link to comment Share on other sites More sharing options...
JCPalmer Posted April 8, 2016 Author Share Posted April 8, 2016 I feel real confident that this works. Reason is I just Gulped / minified a file out of Tower of Babel, and did not get as much compression I used to get. I suspected the reason was Gulp also stripped leading zeros. Here is a pretty old Tower of Babel output that was Gulped. Was not generated with leading zeros removed, but they are gone. (You have to scroll a few pages to the right to see one.) If Gulp is pulling them out, it must work everywhere! Of course, a .babylon file cannot be gulped. The Blender exporter has been generating tighter & tighter files, as indicated from this thread. When this feature finally makes it to the .babylon exporter, chop another 10+% out of the file! dbawel, adam and GameMonetize 3 Quote Link to comment Share on other sites More sharing options...
JCPalmer Posted May 9, 2016 Author Share Posted May 9, 2016 Well the pussy JSON.parse() will not accept values without the leading zero. Sorry .babylon users. In-line JS rules. It works fine in Tower of Babel in-line JS generator. dbawel and GameMonetize 2 Quote Link to comment Share on other sites More sharing options...
GameMonetize Posted May 9, 2016 Share Posted May 9, 2016 Perhaps we should leave only one 0 Quote Link to comment Share on other sites More sharing options...
dbawel Posted May 10, 2016 Share Posted May 10, 2016 @JCPalmer - it is always safe to use additional zeros in interger values. However, as you know, this doesn't often work the other way - by using only integer values. Common example: . // use: pick_color.r, pick_color.g, pick_color.b //var r = parseFloat(pick_color.r) * 255; //var g = parseFloat(pick_color.g) * 255; //var b = parseFloat(pick_color.b) * 255; I've been monitoring my mobile performance tests using XDK to emulate mobile devices, and have found no detectible performance issues in using many variables utilizing float values compared to integer values. We've come a long way baby! DB Quote Link to comment Share on other sites More sharing options...
gryff Posted May 10, 2016 Share Posted May 10, 2016 @dbawel - I think Jeff is looking at things like animations which have values between 0 and 1. 40 bones with 300 frames and 16 float values/per frame - leaving out the leading zero can reduce the file size of the babylon file.. And of course the UVs of meshes. And Jeff has seriously reduced the file size of the babylon export from Blender - still looking for more cheers gryff dbawel 1 Quote Link to comment Share on other sites More sharing options...
dbawel Posted May 10, 2016 Share Posted May 10, 2016 @gryff - yep, that's something I didn't consider. However, I don't see enough substancial memory usage from adding a 0 to non integer values in any case. But good point - I should have read his posts more carefully to see what the whole issue was. DB Quote Link to comment Share on other sites More sharing options...
JCPalmer Posted May 10, 2016 Author Share Posted May 10, 2016 @gryff I think you just saw the last attempt to decrease size for the .babylon format. Even the in-line JS format has only one more 20 - 30% reduction coming. That huge drop when Blender started optimizing meshes when they also had skeleton is not repeatable. Even with the leading zeros gone from the the JS format, the .babylon format is still slightly smaller, initially. That Is because I have tried to make the code as readable as possible with many line breaks and space character based indenting, not tab based. Gulp rips all that out and more, of course. dbawel 1 Quote Link to comment Share on other sites More sharing options...
gryff Posted May 10, 2016 Share Posted May 10, 2016 @JCPalmer. Jeff, I've been impressed with the reductions in file size (as I documented here) and the improvement in readability I've also noticed. But the reduction in file size has also helped with the readability issue too. I use Notepad++ for coding and looking at .babylon files. Notepad++ has always had, for me at least, issues with large files - so with the file size reduction AND the file layout changes for readability, there is a big improvement in how Notepad++ handles .babylon files cheers, gryff Quote Link to comment Share on other sites More sharing options...
JCPalmer Posted May 10, 2016 Author Share Posted May 10, 2016 @dbawel, on the memory representation front, the reason you see no difference between a JS number or array of numbers, whether they are integer or not is: all JS numbers are float 64. Now if you or another .babylon format user was concerned about CPU memory, I would change how vertex data is loaded. Right now, I believe, vertex data is loaded as a JS number[], when coming from a .babylon. The data cannot be passed to openGL like that. A Float32Array object is created and copied to pass data, then thrown away. I changed VertexBuffer to accept & store the array as a Number[] or Float32Array object in BJS 2.3. This enabled the potential for higher morph rates (QueuedInterpoation extension is entirely Float32Array based), since no temp Float32Array need be created / garbage collected every frame. This should also reduce the memory footprint of the biggest things in the VM by 50% being 32 bits instead of 64. The in-line JS format creates permanent Float32Array backers for VertexBuffer, right off the bat. dbawel 1 Quote Link to comment Share on other sites More sharing options...
dbawel Posted May 10, 2016 Share Posted May 10, 2016 @JCPalmer - I assumed it had to be float64 or float32, but duh.... I didn't consider this in my empty mind... I need to think a bit more in the future, Thanks, DB Quote Link to comment Share on other sites More sharing options...
lesterhaus Posted May 11, 2016 Share Posted May 11, 2016 Hey, don't know if this will earn me a "no shit einstein!" .. but I'm going to write it regardless I'm transforming a lot of DXF files to .babylon files and had quite some playtime with this. Since the initial load and the file size was one of my biggest issues I ended up to only include positions and normals in my babylon scene file and calculating UVs in the loading callback. that basically stripped over 1/2 of my filesize. I'd strip the normals too if I could, but I need them for some server side analysis of the meshes. Granted, I'm mainly importing architecture models, so I'm dealing with many "flat" face normals and larger but fewer meshes so I only need to do planar mapping. But the additional time computing the UVs compared to loading a file with UVs at least felt about the same. Anyways, if your use case is remotely close to mine and if it is an option for you, I'd really recommend to compute UVs and even normals on load to reduce the file size. Quote Link to comment Share on other sites More sharing options...
JCPalmer Posted May 11, 2016 Author Share Posted May 11, 2016 Complex textures would not allow for UV calculation, like for this texture for teeth: In fact, BJS can calculate normals. I could put an option in the in-line JS exporter I have for Blender to calc on the BJS side. You can do things like turn things inside out in Blender, so it would have to be optional. Would support BJS calculated normals, if the feature was added for .babylon loading, but I am not adding the feature. Quote Link to comment Share on other sites More sharing options...
